3P 380v50hz or customize
◆ Driven system:
servo motor with gearbox for the cup molds stepping running, it can moving filled cup very fast but avoid
material splash because servo motor can start and stop smoothly,and also high positioning accuracy.
◆ Empty cup loading function
it using spiral separating and pressing technology which can avoid the cup damage and deforming, it has vacuum sucker which guide the cup enter into mold accuracy.
◆ Empty cup detecting function
l it use photoelectric sensor or optical fiber sensor to detect the mold have or haven’t empty cup, it can avoid the mistake
filling,sealing and capping if the mold without the cups, reduce the product waste and machine cleaning time.
* Al-foil lids loading system: it make up by rotate vacuum suckers and al-foil lids magazine, the vacuum suckers get the lids
then rotate 90 degree and place the lid on the filled cups.
* Sealing system:It has PID sealing temperature controller for each sealing mold.
* Date coding system: it make up by rotate print heads and ink cans, the print heads get the ink then rotate 90 degree and print
the date on the sealed cups.
* Discharge system: it make up by cup lifting and pulling system, faster and stable.
* Automation control system: it make up by PLC, Touch screen, servo system, sensor, magnetic valve, relays etc.
* Pneumatic system: it make up by valve, air filter, meter, pressing sensor, magnetic valve, air cylinders, silencer etc.
